Pulse Bag-type Collector
Pulse Bag-type Collector
Request a Quote

Pulse Bag-type Collector

Applications

Our pulse bag-type collectors has a simple structure, convenient installation and maintenance, long service life and high dust collection efficiency; as a result, our industrial dust collectors are widely used for dust pollution control applications in cement and asphalt processing, wood, food, textile, paper, plastic, paint and minerals processing industries.

Features
  • Dust collection types: pulsed dust-collection; separator dust-collection.
  • Rational air distribution enables dust agglomeration during filtering process, which help reduce the load of filter bag and the frequency of pulse.
  • Simple and convenient installation and removal for filter bags. And resistance welded frame is so smooth that avoided abrasion of filter bags.
  • We can choose different filter bags for different requirements.

Parameters
Data \ Spec Filter area (m2) Velocity of wind m/min Thickness of inlet (g/m3) Thickness of output (mg/m3) Running resistance (MPa) Pressure of deashing (MPa) Air consumption m3/min Outside measurement L×W×H
LHZ-40 40 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 0.3 1995×2800×4600
LHZ-60 60 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 0.3 2295×3142×4600
LHZ-92 92 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 0.3 3015×3332×4600
LHZ-120 120 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 0.5 3735×3332×4600
LHZ-150 150 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 0.5 4645×3332×4600
LHZ-225 225 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 0.6 5418×3334×4948
LHZ-285 285 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 1.2 5718×3040×6140
LHZ-410 410 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 1.2 5718×3400×6970
LHZ-635 635 0.5~2 60~300 ≤50 0.78~1.5 0.6~0.7 1.5 5974×3900×8260
